Yamaha Mio M3 125
Rp18.700.000
Harga Update Lihat Pricelist
Malayani Cash dan Kredit
Bonus Kelengkapan:
- Dudukan plat
- Helm
- Plat Sementara
- Tollkit
- Gratis Service 4x Ganti Oli 1x
Description
MESIN
| Tipe Mesin | Air cooled 4-stroke, SOHC |
| Kapasitas Oli Mesin | Total = 0,84 L ; Berkala = 0,80 L |
| Susunan Silinder | Single cylinder |
| Diameter x Langkah | 52,4 x 57,9 mm |
| Perbandingan Kompresi | 9,5 : 1 |
| Volume Silinder | 125 cc |
| Daya Maksimum | 7,0 kW / 8000 rpm |
| Torsi Maksimum | 9.6 Nm / 5500 rpm |
| Sistem Starter | Electric & Kick Starter |
| Sistem Pelumasan | Wet Sump |
| Sistem Bahan Bakar | Fuel Injection |
| Tipe Kopling | Dry, Centrifugal Automatic |
| Tipe Transmisi | V-Belt Automatic |
DIMENSI
| P X L X T | 1870mm X 685mm X 1035mm |
| Jarak Sumbu Roda | 1260 mm |
| Jarak Terendah Ke Tanah | 135 mm |
| Tinggi Tempat Duduk | 750 mm |
| Berat Isi | 92 kg |
| Kapasitas Tangki Bensin | 4,2 L |
RANGKA
| Tipe Rangka | Underbone |
| Suspensi Depan | Teleskopik |
| Suspensi Belakang | Unit Swing |
| Ban Depan | 70/90-14M/C (34P) |
| Ban Belakang | 80/90-14M/C (40P) |
| Rem Depan | Hydraulic Single Disc Brake |
| Rem Belakang | Drum Brake |
KELISTRIKAN
| Sistem Pengapian | TCI |
| Battery | YTZ4V/GTZ4V |
| Tipe Busi | NGK/CR6HSA |
